| AC phase configuration | Single-phase
|
|---|
| Output waveform | Pure sine wave |
|---|
| Battery support | Required |
|---|
| Nominal battery voltage (V) | 12
|
|---|
| Min battery voltage (V) | 9.5 |
|---|
| Max battery voltage (V) | 17.0 |
|---|
| Outage backup capability | Yes |
|---|
| Backup/EPS output power (W) | 1600.0 |
|---|
| Backup output voltage (V) | 120
|
|---|
| Surge output power (W) | 3500.0 |
|---|
| Max AC battery charging current (A) | 80.0 |
|---|
| Generator input supported | Yes |
|---|
| AC input voltage (V) | 120
|
|---|
| AC input frequency (Hz) | 45–65
|
|---|
| Max AC input current (A) | 50.0 |
|---|
| AC pass-through current (A) | 50.0 |
|---|
| Peak efficiency (%) | 93.0 |
|---|
| Idle/no-load consumption (W) | 10.0 |
|---|
| Standby consumption (W) | 3.0 |
|---|
| Efficiency and consumption conditions | Standby consumption is Search mode. |
|---|
| Parallel operation supported | Yes |
|---|
| Max parallel units | 6 |
|---|
| Communication interfaces | VE.Bus
|
|---|
| Monitoring app or portal | Victron VRM |
|---|
| Remote control functions | Remote monitoring, Remote settings, Remote on/off
|
|---|
| Required monitoring accessories | Cerbo GX or another compatible GX device and internet connection
|
|---|
| Monitoring subscription requirements | VRM portal is free of charge. |
|---|
| Length (mm) | 147.0 |
|---|
| Width (mm) | 236.0 |
|---|
| Height (mm) | 506.0 |
|---|
| Weight (kg) | 15.5 |
|---|
| Enclosure rating | IP22 |
|---|
| Min operating temperature (°C) | -40.0 |
|---|
| Max operating temperature (°C) | 65.0 |
|---|
| Cooling method | Fan-cooled |
|---|
