Inverter Specifications
| SKU | GRO-SPH-6000TL |
|---|---|
| Operating type | Grid-tie, Hybrid |
| Inverter function | Inverter/charger |
| Continuous AC output power (W) | 6000.0 |
| AC output rating conditions | Grid output is 6000 W; standalone output is rated 3680 VA. Transfer time is ≤1 s. |
| Continuous apparent power (VA) | 6000.0 |
| AC output voltage (V) | 240, 208 |
| AC output frequency (Hz) | 60 |
Show all specifications (46)Show fewer specifications
| AC phase configuration | Split-phase |
|---|---|
| Nominal battery voltage (V) | 48 |
| Min battery voltage (V) | 42.0 |
| Max battery voltage (V) | 59.0 |
| Outage backup capability | Yes |
| Backup output voltage (V) | 240 |
| Solar PV input supported | Yes |
| Max recommended PV array power (W) | 8000.0 |
| Max DC input voltage (V) | 550.0 |
| PV startup voltage (V) | 150.0 |
| Min MPPT voltage (V) | 150.0 |
| Max MPPT voltage (V) | 550.0 |
| Independent MPPT count | 2 |
| PV strings per tracker | 1 |
| Max PV operating current (A) | 13.0 |
| PV operating-current limit basis | Per tracker |
| Max PV short-circuit current (A) | 16.0 |
| PV short-circuit current limit basis | Per tracker |
| Max combined battery charging current (A) | 75.0 |
| Max combined battery charging power (W) | 3680.0 |
| Peak efficiency (%) | 97.0 |
| Display | LCD and LEDs |
| Communication interfaces | RS232, RS485, CAN, USB |
| Length (mm) | 179.0 |
| Width (mm) | 669.0 |
| Height (mm) | 565.0 |
| Weight (kg) | 33.5 |
| Installation environment | Indoor/outdoor |
| Enclosure rating | NEMA 4X / IP65 |
| Min operating temperature (°C) | -25.0 |
| Max operating temperature (°C) | 60.0 |
| Temperature and altitude derating | Output derates above 45°C. |
| Max operating altitude (m) | 2000.0 |
| Cooling method | Passive |
| Noise measurement conditions | Typical noise ≤25 dB(A). |
| Certifications | UL 1741:2018, CSA C22.2 No. 107.1:2016 |
| Grid standards and listings | IEEE 1547, CA Rule 21, HECO Rule 14H |
| MPN | SPH6000TL BL-US |
Description
**GRID-TIE ONLY**
Key Features:
- AXE Hybrid Inverter can be used Grid-Tied or Off-Grid
- Solar PV input 80-500v, can provide backup supply during grid outage (48VDC system)
- Allows control the level of self-sufficiency and system self-consumption,
- Max 8000W PV (@ 550VDC)
- CSA approved
