SKU: KIS-AC1240
Mfg. SKU: AC1240
The KISAE AC1240 is a 40A multi-stage battery charger designed to deliver reliable charging performance for Gel, AGM, Flooded, and Lithium batteries. With support for up to three battery banks, advanced protections, and programmable charging profiles, this compact unit is ideal for RVs, marine systems, off-grid cabins, and backup power applications in Canada.
Built with universal AC input (90–265VAC), the AC1240 automatically adjusts to global power standards, making it equally dependable in Canadian cottages, marinas, or international use.
Multi-Stage Charging: Ensures batteries are charged to manufacturer-recommended levels with Bulk, Absorption, Float, and Equalize modes.
Battery Compatibility: Supports Gel, AGM, Flooded, and Lithium battery types with selectable charging programs.
Three-Bank Charging: Charges up to three battery banks simultaneously with priority bank charging to ensure your main battery charges first.
User-Friendly Display: Back-lit LCD screen provides real-time voltage, current, charging status, and error codes.
Silent Mode: Quiet operation near sleeping quarters, ideal for RVs and boats.
Flexible Installation: Compact design, easy setup, and optional remote ON/OFF panel (sold separately).
Built-In Protections: Reverse battery protection, short-circuit protection, over-temperature shutdown, and forced-air cooling.
Weather Resistance: IP32-rated enclosure for additional durability.
Output Voltage: 12V
Max Output Current: 40A
Charge Voltage Range: 14.2 – 15.5V
Float Voltage Range: 13.4 – 13.8V
Equalize (Flooded batteries only): 16.0V
Stages: Two or Three, programmable
Parasitic Current: < 2 mA
Battery Banks: 3
AC Input
Voltage: 120, 230, 240VAC (auto-sensing)
Operating Range: 90 – 265VAC
Frequency: 47 – 63Hz
Power Consumption: 700W (full load)
Power Factor Correction: Yes
Enclosure
Connections: Hardwire / Input cord (Schuko, UK, Australia plug options)
DC Output Connection: Heavy-duty studs
Ingress Protection: IP32
Size & Weight
Dimensions: 11.6 × 8.1 × 3.4 in (295 × 206 × 86 mm)
Weight: 5.3 lbs. (2.4 kg)
Why Choose the KISAE AC1240 in Canada?Engineered to meet Canadian energy storage demands, the KISAE AC1240 is compact, efficient, and versatile. Whether you need a dependable charger for your RV, boat, off-grid solar system, or backup power solution, the AC1240 ensures your batteries stay safe, fully charged, and ready when you need them.
